Shijie CamoNet Lite 150D Camouflage Net
Lightweight 150D polyester camouflage net with a reinforced backing mesh for sunshade, visual screening and custom outdoor covering.
Product Overview
The 150D Double-Layer Camouflage Sunshade Net is made with 100% polyester filament fabric and a reinforced nylon backing mesh. It combines a three-dimensional cut-leaf surface with a hand-tied mesh structure, providing lightweight shading, matte visual screening, and flexible installation for outdoor covering applications.
With standard sizes and full custom-cut options, this net can be used for construction site covering, aggregate yard screening, slope greening, garden sunshade, temporary roof covering, outdoor decoration, and irregular equipment wrapping.
Features
• 150D polyester filament fabric
• Lightweight and compact when folded
• Quick installation and removal
• Standard and custom sizes available
• UV-stabilized material for outdoor use
• Optional flame-retardant treatment
Technical Specifications
| Item | Specification |
|---|---|
| Product name | 150D Camouflage Sunshade Net |
| Series | Optical Camouflage and Sunshade Net |
| Model | Shijie CamoNet Lite 150D |
| Surface fabric | 100% polyester filament |
| Fabric weight | 70 ± 10 g/m² |
| Fabric thickness | Approx. 0.12 mm |
| Surface process | 3D die-cut wavy camouflage pattern |
| Backing mesh material | 21-strand standard nylon rope |
| Mesh size | 15 cm × 15 cm square grid |
| Mesh weight | 8 g/m² |
| Breaking strength of individual mesh cord | ≥750 N |
| Connection method | Hand-tied |
| Edge binding | Single-layer edge binding in matching fabric |
| Tie rope spacing | One tie cord at 1 m intervals |
| Finished net weight | 78–90 g/m² |
| Visible light shading rate | 75–85% |
| Light transmittance | ≤1.2% |
| Operating temperature | -30°C to +50°C |
| Outdoor service life | Typically 6–12 months, depending on UV exposure, wind, installation and maintenance |
| Shelf life under recommended indoor storage conditions | Approx. 2 years |
| Wind resistance | Suitable for Beaufort Force 3–4 winds when properly secured |
| Flame retardancy | Optional flame-retardant version available |
Product Construction
This camouflage sunshade net is designed with a cut-leaf polyester surface and a supporting nylon mesh. The surface fabric creates a three-dimensional camouflage effect, while the backing mesh improves structural stability during installation and outdoor use.
Surface Fabric
The surface layer uses 100% polyester filament fabric with a weight of 70 ± 10 g/m² and an approximate thickness of 0.12 mm. The fabric is processed into a three-dimensional die-cut wavy pattern to help break up flat visual outlines and improve the decorative camouflage effect.
Supporting Backing Mesh
The backing mesh is made of 21-strand standard nylon rope. The mesh grid size is 15 cm × 15 cm, with a mesh weight of approximately 8 g/m². Each single mesh rope has a breaking strength of ≥750 N.
Edge Binding and Tie Ropes
The edge is bound with the same fabric and stitched with a single sewing line. Tie ropes are arranged every 1 meter, making the net easy to tension, fix, connect, and install on different structures.
Standard Sizes and Custom Cutting
Standard sizes are available for common outdoor covering and shading projects.
Non-standard sizes can be cut according to project requirements. The length and width tolerance is controlled within ±2%.
Custom Shapes
We manufacture custom dimensions and irregular shapes for non-standard covering projects. Available widths range from 1.5 to 50 m, with lengths of up to 200 m.
Custom cutting options include arcs, fan shapes, trapezoids, irregular polygons, curved covers, equipment wraps and full-slope coverings. Multiple panels can also be joined for large or irregular areas.
Multiple net pieces can also be joined together to match large-area or irregular covering requirements.
Camouflage Colors and Pattern Options
Custom colors can be matched to a supplied sample or selected for a specific background environment, subject to production confirmation.
Jungle Three-Color
Dark green, grass green, and earthy yellow. Commonly used for construction sites, mountain areas, vegetation backgrounds, and outdoor green environments.
Desert Three-Color
Sand yellow, light brown, and earthy brown. Suitable for sand, gravel yards, dry land, and desert-style environments.
Solid Colors
Army green, black, white, and khaki are available for sunshade, decoration, screening, and general outdoor covering.
Pattern Options
• V pattern
• C pattern
• S pattern
Custom color matching can be discussed according to sample, background environment, or project requirements.
Weather, Shading and Optical Screening Performance
The 150D camouflage sunshade net is suitable for outdoor environments from -30°C to +50°C. In extremely cold conditions, the coating may become slightly harder, but it will not crack or peel off under normal use.
The product uses standard UV-resistant additives. Under outdoor exposure, the expected service life is approximately 0.5–1 year. For indoor storage, the storage life is approximately 2 years.
The matte surface helps reduce obvious mirror reflection under strong outdoor light. With a visible light shading rate of 75–85% and light transmittance of ≤1.2%, it provides effective shading and visual screening for many outdoor covering applications.
This model is intended for visible-light shading and visual concealment. It does not provide infrared, thermal or radar signature reduction unless separately specified and supported by test data.
Physical and Mechanical Performance
Item: Technical Indicator
Warp tensile strength: ≥750 N
Weft tensile strength: ≥200 N
Warp tear strength: ≥35 N
Weft tear strength: ≥28 N
The net is designed for normal level 3–4 wind conditions. In strong wind environments, reinforced fixing and edge protection are recommended to reduce abrasion on corners and edges.
Individual Packaging
Each piece is individually packed for convenient carrying, storage, distribution, and on-site installation. Five types of independent packaging bags are available according to customer requirements.
For bulk orders, export packaging can be arranged based on order quantity, shipping method, and destination market.
Request a Custom Quote
Tell us your required size, color, shape, quantity, and application scenario. We can provide standard camouflage sunshade nets, custom-cut irregular shapes, reinforced fixing options, and packaging solutions for your project.
